| ACPI version | 6.0 |
|---|---|
| Audio chip | Realtek ALC887 |
| Audio output channels | 7.1 channels |
| BIOS memory size | 128 Mbit |
| BIOS type | UEFI AMI |
| Compatible processor series | Intel® Celeron®, Intel® Pentium® |
| Component for | PC |
| CPU fan connector | Yes |
| Depth | 238.8 mm |
| DVI-D ports quantity | 1 |
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN | Yes |
| Front panel audio connector | Yes |
| Graphics adapter family | Intel |
| LAN controller | Intel® I219-V |
| Maximum internal memory | 64 GB |
| Memory channels | Dual-channel |
| Memory slots type | DIMM |
| Microphone in | Yes |
| Motherboard chipset | Intel® Z270 |
| Motherboard form factor | Micro ATX |
| Non-ECC | Yes |
| Number of chassis fan connectors | 2 |
| Number of memory slots | 4 |
| Power source type | ATX |
| Processor socket | LGA 1151 (Socket H4) |
| RAID levels | 0,1,5,10 |
| S/PDIF out connector | Yes |
| S/PDIF out port | Yes |
| Supported memory clock speeds | 2133,2400,2666,2800,3000,3200,3300,3333,3400,3466,3600,3733,3866 MHz |
| Unbuffered memory | Yes |
| Wake-on-LAN ready | Yes |
| Width | 243.8 mm |
