| Addressable RGB | No |
|---|---|
| AMD CrossFire Support | 3-Way CrossFire |
| ATX Power connector 24-pin | Yes |
| Audio | Realtek ALC S1220A 7.1 HD Audio + Crystal Sound 3 |
| Audio line in ports | 1 x 8-Channel Audio I/O |
| Bluetooth | No |
| Board dimensions | 305 x 244 mm |
| Chipset | Intel X299 |
| Chipset manufacturer | Intel |
| Clear CMOS button | Yes |
| Colours | Black |
| Component for | Workstation |
| CPU fan connector | Yes |
| CPU Socket | 2066 |
| Depth | 244 mm |
| Dimensions | 23 x 39 x 40cm (W x H x D) |
| Discrete graphics support | Yes |
| Displayport connection | No |
| DVI connection | No |
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN | Yes |
| Ethernet LAN ports | 2 |
| Firewire | No |
| Form factor | ATX |
| HDD interface | Serial ATA III |
| HDMI connection | No |
| Integrated Graphics Supported | No |
| Integrated Network | Intel I210-AT |
| Intel Optane Memory Ready | Yes |
| Internal USB 3.0 Header | Yes |
| M.2 Support | Yes |
| Maximum Installed Processors | 0 (1) |
| Maximum internal memory | 131072 MB |
| Memory channel | Quad |
| Memory slot | 8 x DIMM Slots |
| Memory speed | DDR4 - 2133 DDR4 - 2400 DDR4 - 2666 DDR4 - 3600(OC) DDR4 - 4133(OC) |
| Memory type | DDR4 |
| Memory Type ECC | Non-ECC |
| Memory Type R/U | UDIMM (Unbuffered) |
| Motherboard Power Connectors | 4 + 4-Pin x 2 |
| Multi GPU Support | Both |
| Network Interface Type | Dual Wired Gigabit LAN (10/100/1000) |
| Non-ECC | Yes |
| Number of COM connectors | 1 |
| Number of PCI Express Slots | 5 slot(s) |
| Number of SATA III connectors | 6 |
| On-board Audio Type | 7.1 |
| On-Board Graphics Connectors | None |
| Parallel processing technology support | 3-Way CrossFireX,3-Way SLI |
| Primary GPU Interface | PCIe 3.0 (x16) |
| Processor socket | LGA 2066 (Socket R4) |
| QPI Speed | N/A |
| RAID Format | Chipset: RAID 0, 1, 5, 10 |
| Raid supported | Yes |
| Refresh rate | 60Hz 2Ms Response Time |
| RJ-45 ports | 2 x RJ-45 |
| SATA Connectors | 6 x SATA 6Gb/s |
| SATA III Support | Yes |
| SATA Support | SATA3 / M.2 |
| SATA Supported | Yes |
| Skip audio test | No |
| Supported DIMM module capacities | 16GB |
| Supported memory clock speeds | 2133,2400,2600,3600,4133 MHz |
| Supported processors | Core X-Series Processors |
| Thunderbolt | No |
| TPM connector | Yes |
| USB 3.0 Support | Yes |
| USB 3.1 Support | Yes |
| USB Ports | 10 port(s) |
| VGA connection | No |
| Water Cooled | No |
| Width | 305 mm |
| Wireless Network | No |
