| AMD CrossFire Support | N/A |
|---|---|
| Chassis intrusion connector | Yes |
| Chipset | Intel C232 |
| Compatible processor series | Intel® Celeron®, Intel® Pentium® |
| Component for | Server |
| CPU Socket | 1151 |
| Depth | 244 mm |
| ECC | Yes |
| Ethernet LAN | Yes |
| Form factor | ATX |
| HDD interface | Serial ATA III |
| Integrated Graphics | Integrated ASPEED AST2400 |
| Intel rapid storage technology | No |
| Intel trusted execution technology | Yes |
| LAN controller | Intel I210 |
| Maximum internal memory | 64 GB |
| Memory channel | Dual (2) |
| Memory channels | Dual-channel |
| Memory speed | DDR4 - 2133 DDR4 - 2400 |
| Memory type | UDIMM |
| Non-ECC | Yes |
| Number of DIMM slots | 4 |
| Number of SATA III connectors | 6 |
| On-Board Graphics Connectors | D-Sub (VGA) |
| Primary GPU Interface | PCIe 3.0 (x16) / Aspeed AST2400 32MB Onboard |
| Processor manufacturer | Intel |
| Processor socket | LGA 1151 (Socket H4) |
| Rear I/O Connectors | 4 x 10/100/1000 (LAN) 1 x D-Sub (VGA) Out 1 x Mgmt LAN 1 x PS/2 Keyboard 2 x USB 2.0 2 x USB 3.1 |
| SATA Support | SATA3 / M.2 |
| Supported memory clock speeds | 2133 MHz |
| TPM connector | Yes |
| USB 2.0 connectors | 1 |
| Water Cooled | No |
| Wi-Fi | No |
| Width | 305 mm |
