| AMD CrossFire Support | Not Supported |
|---|---|
| Audio | N/A |
| Board dimensions | 305mm x 330mm mm |
| Chipset | Intel C612 PCH |
| CPU Socket | 2011-3 x2 |
| Expansion slots | 1 x M.2, 22-42, SATA 1 x PCIe 3.0 x16 2 x PCIe 3.0 x8 |
| Form factor | SSI EEB |
| Integrated Graphics | Integrated ASPEED AST2400 |
| Maximum memory capacity | 1024GB |
| Memory channel | Quad (4) |
| Memory speed | DDR4 - 1333 DDR4 - 1600 DDR4 - 1866 DDR4 - 2133 |
| Memory Type R/U | RDIMM / LRDIMM / NVDIMM |
| Network Interface Type | Dual Wired 10G LAN + Mgmt LAN |
| On-Board Graphics Connectors | D-Sub (VGA) |
| Primary GPU Interface | On-board |
| QPI Speed | 6.4 GT/s |
| RAID Support via | Support Software RAID 0, 1, 5, 10 |
| Rear I/O Connectors | 1 x D-Sub (VGA) Out 1 x PS/2 Keyboard/Mouse Combo 2 x RJ-45 1 x RJ-45 Mgmt LAN 2 x USB 3.0 |
| SATA Support | SATA3 |
| Storage Mode Support | Intel Rapid Storage Technology Enterprise RAID 0 RAID 1 RAID 10 RAID 5 |
| Water Cooled | No |
