Samsung 970 EVO Plus 500GB M.2-2280 PCI-e 3.0 x 4 NVMe Solid State Drive SSD

999999.99 EUR

The Samsung 970 EVO 500 GB M.2 NVMe SSD delivers 3,400 MB/s read and 2,300 MB/s write speeds, powered by a Phoenix controller and V‑NAND 3‑bit MLC. It features 256‑bit AES encryption, a 512 MB cache, and a slim 22 mm profile for compact systems.

Brand: Samsung
Model: MZ-V7E500BW
MPN: MZ-V7E500BW
Sponsored  This site contains affiliate links for which we may receive compensation. More information
4K Random Read AS SSD Up to 370,000 IOPS
4K Random Write AS SSD Up to 450,000 IOPS
Colour Zwart
Component for PC
Controller type Samsung Phoenix
Depth 22,1 mm
Disk Capacity 500 GB
Disk form factor M.2 2280
Electrical Power Consumption 6 W
Electrical Power Consumption Standby 5 mW
Encryption AES 256 bit
Form factor Solid State Drive
Hardware encryption Ja
Height 2,38 mm
Interface PCI Express 3.0
Interface type PCIe 3.0 x4 NVMe 1.3
Launch date 4/16/2018
Mean Time Between Failure MTBF 1,500,000 hours
Memory Package V-NAND 3bit MLC
Memory type V-NAND MLC
Non-operating shock 1500 G
Non-operating vibration 20 G
NVMe version 1.3
Opal SSC 2.0 Yes
Operating humidity 5% ~ 95%
Operating voltage 3,3 V
PCI Express interface data lanes x4
Power consumption (read) 5.7 W
Power consumption write 5,8 W
Read speed 3400 MB/s
S.M.A.R.T. support Yes
Security TCG/Opal V2.0Encrypted Drive (IEEE1667)
Shock non operating 1,500G @ 0.5ms
Solid state drive Yes
SSD form factor M.2
Sustainability certificates RoHS
TCG Opal 2.0 Yes
Vibration non-operating 20 ~ 2,000Hz, 20G
Width 80,2 mm
Write speed 2300 MB/s
