| ACPI version | 6.1 |
|---|---|
| AMD CrossFire Support | 2-Way CrossFire |
| Audio | 8-Channel(7.1) HD Audio with Audio Boost |
| Audio chip | Realtek ALC892 |
| Audio output channels | 7.1 channels |
| BIOS memory size | 128 Mbit |
| BIOS type | UEFI AMI |
| Cables included | SATA |
| Chassis intrusion connector | Yes |
| Chipset | Intel Z390 |
| Component for | PC |
| CPU fan connector | Yes |
| CPU Socket | 1151 |
| Depth | 304 mm |
| Digital Audio Optical Out | 1 |
| Drivers included | Yes |
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN | Yes |
| Form factor | ATX |
| Front panel audio connector | Yes |
| Front panel connector | Yes |
| LAN controller | Intel® I211-AT, Intel I219V |
| Manual | Yes |
| Maximum internal memory | 64 GB |
| Maximum memory capacity | 64GB (4x16GB) |
| Maximum resolution | 4096 x 2304 pixels |
| Memory channels | Dual-channel |
| Memory slots type | DIMM |
| Memory speed | DDR4 - 2133 DDR4 - 2400 DDR4 - 2666 DDR4 - 4400(OC) |
| Memory type | DDR4 |
| Memory Type ECC | Non-ECC |
| Memory Type R/U | UDIMM (Unbuffered) |
| Motherboard chipset family | Intel |
| Network Interface Type | Dual Wired Gigabit LAN (10/100/1000) |
| Non-ECC | Yes |
| Number of chassis fan connectors | 5 |
| Number of SATA III connectors | 6 |
| NVIDIA SLI Support | Not Supported |
| On-Board Graphics Connectors | DisplayPort 1.2 HDMI |
| PC Health Monitoring | CPU,FAN,Temperature |
| Primary GPU Interface | PCIe 3.0 (x16) |
| Processor socket | LGA 1151 (Socket H4) |
| QPI Speed | N/A |
| Quick installation guide | Yes |
| RAID levels | 0,1,5,10 |
| S/PDIF out port | Yes |
| SATA Support | SATA3 / M.2 |
| Storage Mode Support | Intel Optane Memory Ready NVMe Boot (via M.2 PCIe Slot) NVMe Boot (via PCIe 3.0 Slot) |
| Supported memory clock speeds | 2133,2400,2666,2800,3000,3200,3300,3333,3400,3466,3600,3733,3866,4000,4133,4200,4266,4300,4400 MHz |
| TPM connector | Yes |
| Unbuffered memory | Yes |
| Water Cooled | No |
| Width | 243 mm |
| Windows operating systems supported | Windows 10 Education x64,Windows 10 Enterprise x64,Windows 10 Home x64,Windows 10 Pro x64 |
