| ACPI version | 2.0a |
|---|---|
| Audio chip | Realtek ALC892 |
| Audio output | 6 |
| Audio output channels | 7.1 channels |
| BIOS memory size | 64 Mbit |
| BIOS type | UEFI |
| Bundled software | ASUS Update ASUS Utilities |
| Cables included | CrossFire,SATA |
| Chassis intrusion connector | Yes |
| Clear CMOS jumper | Yes |
| Compatible processor series | AMD Phenom FX,AMD Phenom II X2,AMD Phenom II X3,AMD Phenom II X4,AMD Phenom II X6,AMD Phenom II X8 |
| Component for | PC |
| Controller interface type | AMD SB950 |
| Cooling type | Passive |
| CPU fan connector | Yes |
| Depth | 244 mm |
| Drivers included | Yes |
| eSATA ports quantity | 2 |
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN | Yes |
| Front panel audio connector | Yes |
| LAN controller | Realtek RTL8111F |
| Maximum internal memory | 32 GB |
| Maximum number of SMP processors | 1 |
| Memory channels | Dual-channel |
| Memory slots type | DIMM |
| Microphone in | Yes |
| Motherboard chipset | AMD 990FX |
| Motherboard chipset family | AMD |
| Motherboard form factor | ATX |
| Non-ECC | Yes |
| Number of chassis fan connectors | 4 |
| Number of SATA III connectors | 8 |
| On-board graphics adapter | No |
| Parallel processing technology support | Quad-GPU CrossFireX,Quad-GPU SLI |
| PCI Express configurations | 1x1,1x4,1x16,2x8,2x16 |
| Processor socket | Socket AM3+ |
| Quick installation guide | Yes |
| RAID levels | 0,1,5,10 |
| S/PDIF out connector | Yes |
| S/PDIF out port | Yes |
| Supported memory clock speeds | 1066,1333,1600,1866 MHz |
| Supported storage drive interfaces | Serial ATA III |
| System bus rate | 5.2 GT/s |
| TPM connector | Yes |
| Trial software | Antivirus |
| Unbuffered memory | Yes |
| Width | 305 mm |
