| 64-bit Support | Yes |
|---|---|
| Addressable RGB | No |
| Audio line in ports | 1 x 3.5mm Jack |
| Bluetooth | No |
| Chipset manufacturer | Intel |
| Colour | Black |
| Cooling fan support | 1 x CPU Fan2 x Chassis Fans |
| CPU Socket | Socket 1151 |
| Displayport connection | No |
| Drivers | Included |
| DVI connection | Yes |
| Firewire | No |
| Form factor | Micro-ATX Motherboard |
| Front panel connectors | 1 x Front Panel1 x Front Audio |
| HDMI connection | Yes |
| HDMI Port | 1 x HDMI |
| Integrated Graphics Supported | Yes |
| Internal USB 3.0 Header | Yes |
| Length | 231 mm |
| M.2 Support | Yes |
| Maximum Installed Processors | 0 (1) |
| Maximum RAM | 64 GB |
| Memory Bus Speed | 2666 / 2400 / 2133 MHz |
| Memory channel | Dual |
| Memory slot | 4 x DIMM |
| Memory speed | 2666 MHz |
| Motherboard chipset | Intel B360 |
| Motherboard form factor | mATX |
| Motherboard Power Connectors | 4 + 4-Pin |
| Multi GPU Support | No |
| Network Speeds Supported | 10/100/1000 Mbps |
| Number of PCI Express Slots | 1 x PCI Express 3.0 x162 x PCI Express 3.0 x1 |
| Number of SATA Ports | 6 port(s) |
| On-board Audio Type | 7.1 |
| On-board RGB Control | ASUS Aura Sync |
| Other Connectors | 2 x M.2, Socket 3, M Key (Type 2242/2260/2280)1 x Aura RGB Strip header |
| Power connector port | 1 x 20+4-pin ATX1 x 4+4-pin CPU |
| Raid supported | No |
| RJ-45 ports | 1 x RJ-45 |
| SATA III Support | Yes |
| SATA Supported | Yes |
| Skip audio test | No |
| Software Included | ASUS UtilitiesEZ UpdateAnti-virus software (OEM version) |
| Thunderbolt | No |
| USB 3.0 Support | Yes |
| USB 3.1 Support | Yes |
| USB Connectors | 1 x USB 3.02 x USB 2.0 |
| USB Ports | 5 port(s) |
| VGA connection | No |
| Width | 244 mm |
| Wireless Network | No |
