| 12v power connector | Yes |
|---|---|
| AMD CrossFire Support | Not Supported |
| Audio | Realtek ALC887 7.1 HD Audio |
| Board dimensions | 226 x 21.1 mm |
| Chipset | Intel B460 |
| Cooling | Passive Heatsinks |
| CPU Socket | 1200 |
| Expansion slots | 1 x M.2, 22-42/60/80, PCIe Gen3/SATA3 2 x PCIe 3.0 x1 1 x PCIe 3.0 x16 |
| Form factor | MicroATX |
| Integrated Graphics | Requires Processor Graphics or Discrete GPU |
| LAN controller | Realtek RTL8111H |
| Maximum memory capacity | 64GB |
| Memory channel | Dual (2) |
| Memory slots type | DIMM |
| Memory speed | DDR4 - 2133 DDR4 - 2400 DDR4 - 2666 DDR4 - 2800 DDR4 - 2933 |
| Memory type | DDR4 |
| Memory Type ECC | Non-ECC |
| Memory Type R/U | UDIMM (Unbuffered) |
| Motherboard chipset family | Intel |
| Network Chip | 1 x Realtek RTL8111H (Gigabit LAN) |
| Network Interface Type | Wired Gigabit LAN (10/100/1000) |
| Number of M.2 M slots | 1 |
| On-Board Graphics Connectors | D-Sub (VGA) DVI-D |
| Primary GPU Interface | PCIe 3.0 (x16) |
| QPI Speed | N/A |
| RAID Support via | Intel® SATA RAID 0/1/10/5 |
| Rear I/O Connectors | 1 x 10/100/1000 (LAN) 3 x Audio I/O 1 x D-Sub (VGA) 1 x DVI-D 2 x USB 2.0 4 x USB 3.2 Gen1 Type-A |
| SATA Support | SATA3 |
| Supported storage drive interfaces | SATA III |
| Water Cooled | No |
