| 64-bit Support | Yes |
|---|---|
| ACPI version | 6.1 |
| Addressable RGB | No |
| ATX Power connector 24-pin | Yes |
| Audio chip | Realtek ALC887 |
| Audio line in ports | 1 x 3.5mm Jack |
| Audio output channels | 7.1 channels |
| BIOS memory size | 16 MB |
| BIOS type | UEFI AMI |
| Bluetooth | No |
| Cables included | SATA |
| Chassis intrusion connector | Yes |
| Chipset manufacturer | Intel |
| Colour | Black |
| Compatible processor series | Intel® Celeron®, Intel® Core™ i3, Intel Core i5, Intel Core i7, Intel® Pentium® |
| Component for | PC |
| Cooling fan support | 1 x CPU Fan1 x Chassis Fan |
| CPU fan connector | Yes |
| CPU Socket | Socket 1151 |
| Depth | 208 mm |
| Digital port | 1 x DVI |
| Discrete graphics support | Yes |
| Displayport connection | No |
| Drivers | Included |
| Drivers included | Yes |
| DVI connection | Yes |
| ECC | No |
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN | Yes |
| Firewire | No |
| Form factor | Micro-ATX Motherboard |
| Front panel audio connector | Yes |
| HDMI connection | Yes |
| Integrated Graphics Supported | Yes |
| Intel Extreme Memory Profile XMP | Yes |
| Intel Optane Memory Ready | Yes |
| Internal USB 3.0 Header | Yes |
| LAN controller | Intel I219V |
| M.2 Support | Yes |
| Manual | Yes |
| Maximum Installed Processors | 0 (1) |
| Maximum internal memory | 32768 MB |
| Maximum resolution | 4096 x 2160 pixels |
| Memory Bus Speed | 2666 / 2400 / 2133 MHz |
| Memory channel | Dual |
| Memory slot | 2 x DIMM |
| Memory slots type | DIMM |
| Memory speed | 2666 MHz |
| Memory type | DDR4 |
| Microphone in | Yes |
| Motherboard chipset | Intel B360 |
| Motherboard form factor | mATX |
| Motherboard Power Connectors | 4 + 4-Pin |
| Multi GPU Support | No |
| Network Speeds Supported | 10/100/1000 Mbps |
| Non-ECC | Yes |
| Number of PCI Express Slots | 1 x PCI Express 3.0 x162 x PCI Express 3.0 x1 |
| Number of SATA III connectors | 6 |
| On-board graphics adapter | Yes |
| On-board RGB Control | ASUS Aura Sync |
| Other Connectors | 1 x M.2, Socket 3, M Key (Type 2242/2260/2280)1 x RGB Header |
| Plug and play | Yes |
| Power connector port | 1 x 20+4-pin ATX1 x 4+4-pin CPU |
| Power source type | ATX |
| Processor socket | LGA 1151 (Socket H4) |
| Raid supported | No |
| RJ-45 ports | 1 x RJ-45 |
| S/PDIF out connector | Yes |
| SATA III Support | Yes |
| SATA Supported | Yes |
| Skip audio test | No |
| Software Included | ASUS UtilitiesEZ UpdateAnti-virus software (OEM version) |
| Supported memory clock speeds | 2133,2400,2666 MHz |
| System management BIOS SMBIOS version | 3.1 |
| Thunderbolt | No |
| Unbuffered memory | Yes |
| USB 3.0 Support | Yes |
| USB 3.1 Support | Yes |
| USB Connectors | 1 x USB 3.02 x USB 2.0 |
| VGA connection | No |
| Width | 226 mm |
| Windows operating systems supported | Windows 10 |
| Wireless Network | No |
