| Built-in display | Yes |
|---|---|
| Bus Type | QPI |
| Cabling technology | 10/100/1000Base-T(X) |
| Card reader integrated | Yes |
| Chassis type | Rack (2U) |
| Compatible memory cards | SD |
| Compatible processor series | Intel® Xeon® |
| Dell E-Value Code | PER73005a |
| Depth | 684 mm |
| Display | LCD |
| ECC | Yes |
| ECC supported by processor | Yes |
| Embedded options available | Yes |
| Enhanced intel speedstep technology | Yes |
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN | Yes |
| Execute disable bit | Yes |
| FSB Parity | No |
| Graphics adapter | G200eR2 |
| Graphics adapter family | Matrox |
| HDD Capacity | 300 GB |
| HDD interface | Serial Attached SCSI (SAS) |
| HDD size | 2.5" |
| Height | 87.3 mm |
| Hot-Plug support | Yes |
| Idle states | Yes |
| Intel 64 | Yes |
| Intel Demand Based Switching | Yes |
| Intel enhanced halt state | Yes |
| Intel flex memory access | No |
| Intel trusted execution technology | Yes |
| Intel TSX-NI | Yes |
| Internal memory | 32 GB |
| Internal memory type | DDR4-SDRAM |
| LAN controller | Broadcom 5720 |
| Maximum graphics adapter memory | 16 MB |
| Maximum internal memory | 768 GB |
| Maximum internal memory supported by processor | 1536 GB |
| Maximum number of PCI Express lanes | 40 |
| Maximum storage capacity | 14 TB |
| Memory channels supported by processor | Quad |
| Memory clock speed | 2133 MHz |
| Memory clock speeds supported by processor | 1600,1866,2133,2400 MHz |
| Memory slots | 24 |
| Motherboard chipset | Intel C610 |
| Non-operating altitude | 0 - 12000 m |
| Number of HDDs installed | 1 |
| Number of HDDs supported | 8 |
| Operating altitude | 0 - 3048 m |
| Operating system installed | No |
| Optical drive type | DVD-RW |
| PCI Express configurations | x4, x8, x16 |
| PCI Express slots version | 3.0 |
| Power supply | 750 W |
| Power supply input frequency | 50 - 60 Hz |
| Processor ARK ID | 91767 |
| Processor boost frequency | 2.9 GHz |
| Processor cache type | Smart Cache |
| Processor code | SR2N3 |
| Processor codename | Broadwell |
| Processor cores | 12 |
| Processor family | Intel® Xeon® E5 v4 |
| Processor frequency | 2.2 GHz |
| Processor manufacturer | Intel |
| Processor model | E5-2650V4 |
| Processor operating modes | 64-bit |
| Processor package size | 52.5 x 51 mm |
| Processor series | Intel Xeon E5-2600 v4 |
| Processor socket | LGA 2011-v3 |
| Rack mounting | Yes |
| RAID levels | 0,1,5,6,10,50,60 |
| RAID support | Yes |
| Stepping | M0 |
| Supported instruction sets | AVX 2.0 |
| Supported storage drive interfaces | SAS,Serial ATA |
| System bus rate | 9.6 GT/s |
| Tcase | 80 °C |
| Thermal monitoring technologies | Yes |
| Weight | 18.9 kg |
| Width | 444 mm |
