Eaton ePDU G3 Basic Rack-Mountable Power Distribution Unit

A compact 0U rack‑mount PDU that draws up to 11 kW from a 400 V three‑phase source, offering 24 AC outlets (21 C13 and 3 C19) with LED status indicators, SNMP/Telnet remote control, and an included 3 m RJ‑45 LAN cable.

Brand: Eaton
Model: EBAB20
MPN: EBAB20
SKU: EBAB20
Sponsored  This site contains affiliate links for which we may receive compensation. More information
AC input frequency 50 Hz
AC outlet types C13 coupler,C19 coupler
Cable colour Black
Cable length 3 m
Cables included LAN (RJ-45)
Depth 53 mm
Firmware upgradeable Yes
Form Factor Rackmount
Height 1070 mm
LED indicators Yes
Management protocols SNMP, Telnet
Maximum current 16 A
Maximum power 11000 W
Mounting Vertical
Nominal input voltage 400 V
Nominal output voltage 230 V
Output connections 21 x C13 & 3 x C19
Package depth 214 mm
Package Height 1200 mm
Package width 200 mm
PDU types Basic
Rack capacity 0U
Rack mount kit Yes
Rack mounting Yes
RoHS compliance Yes
Type Three-phase
Weight 2.2 kg
Width 52 mm
