| 12v power connector | Yes |
|---|---|
| 24-pin ATX Power | 1 |
| 64-bit Support | Yes |
| ACPI version | 5.0 |
| Addressable RGB | No |
| AMD CrossFire Support | N/A |
| ATX Power connector 24-pin | Yes |
| Audio | Realtek ALC887 7.1 HD Audio |
| Audio chip | Realtek ALC887 |
| Audio connector | Yes |
| Audio line in ports | 1 x 3.5mm Jack |
| Audio output channels | 7.1 channels |
| Back Audio Jacks | 3 |
| Back USB 2.0 ports | 2 |
| Back USB 3.1 Ports Type-A Gen 1 | 4 |
| BIOS | 1 x 128 Mbit flashUse of licensed AMI UEFI BIOSPnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| BIOS memory size | 128 Mbit |
| BIOS type | UEFI AMI |
| Bluetooth | No |
| Bundled software | Norton Internet Security, cFosSpeed |
| Cables included | SATA |
| Chipset | AMD A320 |
| Chipset manufacturer | AMD |
| Clear CMOS jumper | Yes |
| Colour | Black |
| Compatible processor series | AMD A,AMD Athlon,AMD Ryzen |
| Component for | PC |
| Cooling fan support | 1 x CPU Fan1 x System Fan |
| CPU fan connector | Yes |
| Depth | 195 mm |
| Desktop Management Interface (DMI) version | 2.7 |
| Displayport connection | No |
| Drivers | Included |
| Drivers included | Yes |
| DVI connection | Yes |
| ECC | Yes |
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN | Yes |
| Firewire | No |
| Form factor | MicroATX |
| Front panel audio connector | Yes |
| Front panel connector | Yes |
| Graphics memory | 2048 MB |
| Graphics memory type | Shared |
| Gross weight | 0.72Kg |
| HDMI connection | Yes |
| HDMI version | 1.4 |
| Integrated Graphics Supported | Yes |
| Intel Extreme Memory Profile XMP | Yes |
| Internal USB 3.0 Header | Yes |
| LAN Speed | 10/100/1000 |
| M.2 Support | Yes |
| Manual | Yes |
| Maximum Installed Processors | 0 (1) |
| Maximum internal memory | 32 GB |
| Maximum memory capacity | 32GB (2x16GB) |
| Maximum resolution | 4096 x 2160 pixels |
| Memory Bus Speed | Up to 3200 MHz |
| Memory channel | Dual |
| Memory slots type | DIMM |
| Memory speed | DDR4 - 2133 DDR4 - 2400 DDR4 - 2666 DDR4 - 2933(OC) DDR4 - 3200(OC) |
| Memory Type ECC | ECC/Non-ECC |
| Memory Type R/U | UDIMM (Unbuffered) |
| Microphone in | Yes |
| Motherboard form factor | mATX |
| Motherboard Power Connectors | 8-Pin |
| Multi GPU Support | No |
| Non-ECC | Yes |
| Number of PCI Express Slots | 1 x PCI Express 3.0 x16 slot2 x PCI Express 2.0 x1 slots |
| On-Board LAN | Realtek |
| On-board RGB Control | None |
| Other Connectors | 1 x M.2, Socket 3, M Key (Type 2242/2260/2280/22110) |
| PC health monitoring | FAN,Temperature,Voltage |
| Plug and play | Yes |
| Power connector port | 1 x 20+4-pin ATX1 x 4+4-pin EPS |
| Primary GPU Interface | PCIe 3.0 (x16) |
| RAID | Raid 0/1/10 |
| Raid supported | Yes |
| RAM Slots | 2 x 288-pin |
| RJ-45 ports | 1 x RJ-45 |
| S/PDIF out connector | Yes |
| SATA III Support | Yes |
| SATA Supported | Yes |
| Skip audio test | No |
| Storage Mode Support | RAID 0 RAID 1 RAID 5 |
| Supported memory clock speeds | 2133,2400,2667,2933,3200 MHz |
| Thunderbolt | No |
| TPM connector | Yes |
| Unbuffered memory | Yes |
| USB 3.0 Support | Yes |
| USB 3.1 Support | No |
| USB Connectors | 1 x USB 3.02 x USB 2.0 |
| USB Ports | 6 port(s) |
| VGA connection | No |
| Water Cooled | No |
| Width | 244 mm |
| Wireless LAN | No |
| Wireless Network | No |
