| ACPI version | 5.0 |
|---|---|
| Audio chip | Realtek ALC892 |
| Audio output channels | 7.1 channels |
| BIOS memory size | 64 Mbit |
| BIOS type | UEFI AMI |
| Bluetooth | Yes |
| Bluetooth version | 4.0 |
| Chassis intrusion connector | Yes |
| Clear CMOS jumper | Yes |
| Compatible processor series | Intel® Celeron®, Intel® Pentium® |
| Component for | PC |
| CPU fan connector | Yes |
| Depth | 170 mm |
| DVI-I ports quantity | 1 |
| Ethernet LAN | Yes |
| Front panel audio connector | Yes |
| HDMI ports quantity | 2 |
| HDMI version | 1.4a |
| Headphone outputs | 5 |
| Maximum graphics adapter memory | 1000 MB |
| Maximum internal memory | 16 GB |
| Maximum resolution | 4096 x 2160 pixels |
| Memory channels | Dual-channel |
| Memory slots type | DIMM |
| Microphone in | Yes |
| Motherboard chipset | Intel® H97 |
| Motherboard chipset family | Intel |
| Motherboard form factor | Mini ITX |
| Non-ECC | Yes |
| Number of SATA connectors | 6 |
| Power source type | ATX |
| Processor socket | LGA 1150 (Socket H3) |
| RAID levels | 0,1,5,10 |
| S/PDIF out connector | Yes |
| S/PDIF out port | Yes |
| Supported memory clock speeds | 1333,1600 MHz |
| Supported memory types | DDR3-SDRAM |
| Supported storage drive interfaces | Serial ATA |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11a,Wi-Fi 5 (802.11ac),802.11b,802.11g,Wi-Fi 4 (802.11n) |
| Windows operating systems supported | Yes |
