| Audio chip | Conexant CX20632 |
|---|---|
| Audio system | High Definition Audio |
| Bus Type | OPI |
| Card reader integrated | No |
| Chassis type | Mini PC |
| Configurable TDP-down frequency | 800 MHz |
| Country of origin | China |
| Depth | 175 mm |
| Discrete graphics adapter | No |
| Discrete graphics adapter model | Not available |
| Display included | No |
| DVI port | No |
| ECC supported by processor | No |
| Embedded options available | No |
| Enhanced intel speedstep technology | Yes |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Execute disable bit | Yes |
| Graphics & IMC lithography | 14 nm |
| HDMI ports quantity | 1 |
| Height | 34 mm |
| HP segment | Business |
| Idle states | Yes |
| Intel 64 | Yes |
| Intel clear video technology | Yes |
| Intel enhanced halt state | Yes |
| Intel flex memory access | Yes |
| Intel Identity Protection Technology version | 1.00 |
| Intel trusted execution technology | No |
| Intel TSX-NI | No |
| Intel TSX-NI version | 0.00 |
| Internal memory | 8 GB |
| Internal memory type | DDR4-SDRAM |
| Keyboard included | Yes |
| Maximum internal memory supported by processor | 32 GB |
| Maximum number of PCI Express lanes | 12 |
| Memory channels | Dual-channel |
| Memory clock speed | 2133 MHz |
| Memory clock speeds supported by processor | 1600,1866,2133 MHz |
| Memory slots | 2x SO-DIMM |
| Memory types supported by processor | DDR3L,DDR4-SDRAM,LPDDR3-SDRAM |
| Microphone in | No |
| On-board graphics adapter | Yes |
| On-board graphics adapter base frequency | 300 MHz |
| On-board graphics adapter DirectX version | 12.0 |
| On-board graphics adapter ID | 0x5916 |
| On-board graphics adapter model | Intel® HD Graphics 620 |
| On-board graphics adapter OpenGL version | 4.4 |
| Operating system architecture | 64-bit |
| Operating system installed | Windows 10 Pro |
| Optical drive type | No |
| Package depth | 128 mm |
| Package Height | 223 mm |
| Package width | 497 mm |
| PCI Express configurations | 1x2+2x1,1x4,2x2,4x1 |
| PCI Express slots version | 3.0 |
| Placement supported | Horizontal |
| Power supply | 65 W |
| Processor ARK ID | 95443 |
| Processor boost frequency | 3.10 GHz |
| Processor cache | 3 MB |
| Processor cache type | Smart Cache |
| Processor codename | Kaby Lake |
| Processor family | 7th gen Intel® Core™ i5 |
| Processor frequency | 2.50 GHz |
| Processor manufacturer | Intel |
| Processor model | i5-7200U |
| Processor package size | 42 x 24 mm |
| Processor socket | BGA 1356 |
| SSD Capacity | 256 GB |
| Stepping | H0 |
| Storage media | SSD |
| Supported instruction sets | AVX 2.0,SSE4.1,SSE4.2 |
| Thermal monitoring technologies | Yes |
| Weight | 1.25 kg |
| Wi-Fi | No |
| Width | 177 mm |
