| Bus Type | DMI3 |
|---|---|
| Card reader integrated | No |
| Chassis type | Mini PC |
| Country of origin | China |
| Depth | 216 mm |
| Discrete graphics adapter | No |
| Discrete graphics adapter model | Not available |
| Display included | No |
| DVI port | No |
| ECC supported by processor | Yes |
| Embedded options available | Yes |
| Enhanced intel speedstep technology | Yes |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Execute disable bit | Yes |
| Graphics & IMC lithography | 14 nm |
| Height | 58 mm |
| Idle states | Yes |
| Intel 64 | Yes |
| Intel clear video technology | Yes |
| Intel enhanced halt state | Yes |
| Intel trusted execution technology | Yes |
| Intel TSX-NI | Yes |
| Internal memory | 16 GB |
| Internal memory type | DDR4-SDRAM |
| Maximum internal memory | 32 GB |
| Maximum internal memory supported by processor | 64 GB |
| Maximum on-board graphics adapter memory | 1.7 GB |
| Memory channels | Dual-channel |
| Memory clock speeds supported by processor | 1333,1600,1866,2133 MHz |
| Memory types supported by processor | DDR3L-SDRAM,DDR4-SDRAM |
| Memory voltage supported by processor | 1.35 V |
| Microphone in | No |
| Motherboard chipset | Intel® C236 |
| Number of processors installed | 1 |
| On-board graphics adapter | Yes |
| On-board graphics adapter base frequency | 400 MHz |
| On-board graphics adapter DirectX version | 12.0 |
| On-board graphics adapter ID | 0x191D |
| On-board graphics adapter model | Intel® HD Graphics P530 |
| On-board graphics adapter OpenGL version | 4.4 |
| Operating system installed | Windows 7 Professional |
| Optical drive type | No |
| PCI Express configurations | 1x16,1x8+2x4,2x8 |
| PCI Express slots version | 3.0 |
| Placement supported | Horizontal |
| Power supply | 200 W |
| Processor ARK ID | 88168 |
| Processor boost frequency | 3.70 GHz |
| Processor cache | 8 MB |
| Processor cache type | Smart Cache |
| Processor codename | Skylake |
| Processor family | Intel® Xeon® E3 v5 |
| Processor frequency | 3.3 GHz |
| Processor manufacturer | Intel |
| Processor model | E3-1225V5 |
| Processor package size | 37.5 x 37.5 mm |
| Processor series | Intel Xeon E3-1200 v5 |
| Processor socket | LGA 1151 (Socket H4) |
| Product Type | Workstation |
| SSD Capacity | 256 GB |
| Storage media | SSD |
| Supported instruction sets | AVX 2.0,SSE4.1,SSE4.2 |
| Thermal monitoring technologies | Yes |
| Volume | 2.5 L |
| Weight | 2.04 kg |
| Wi-Fi | No |
