| Box | Yes |
|---|---|
| Bus bandwidth | 8 |
| Bus Type | QPI |
| Bus type units | GT/s |
| Cache memory | 15 MB |
| Component for | Server/Workstation |
| ECC | Yes |
| Embedded options available | Yes |
| Enhanced intel speedstep technology | Yes |
| Execute disable bit | Yes |
| Idle states | Yes |
| Intel 64 | Yes |
| Intel Demand Based Switching | Yes |
| Intel enhanced halt state | Yes |
| Intel flex memory access | No |
| Intel Identity Protection Technology version | 0.00 |
| Intel Secure Key Technology version | 1.00 |
| Intel trusted execution technology | Yes |
| Intel TSX-NI | No |
| Launch date | Q3'14 |
| Market segment | SRV |
| Maximum internal memory | 786432 MB |
| Maximum internal memory supported by processor | 768 GB |
| Maximum number of PCI Express lanes | 40 |
| Memory channels | Quad-channel |
| Memory clock speeds supported by processor | 1600,1866 MHz |
| Memory types supported by processor | DDR4-SDRAM |
| Number of QPI links | 2 |
| On-board graphics adapter | No |
| Package depth | 140 mm |
| Package Height | 117 mm |
| Package width | 44 mm |
| PCI Express CEM Revision | 3.0 |
| PCI Express configurations | x4, x8, x16 |
| Processor ARK ID | 83352 |
| Processor boost frequency | 3.2 GHz |
| Processor cache type | Smart Cache |
| Processor code | SR207 |
| Processor codename | Haswell |
| Processor cores | 6 |
| Processor family | Intel Xeon E5 v3 |
| Processor frequency | 2.4 GHz |
| Processor lithography | 22 nm |
| Processor manufacturer | Intel |
| Processor model | E5-2620V3 |
| Processor operating modes | 64-bit |
| Processor package size | 52.5 x 45 mm |
| Processor series | Intel Xeon E5-2600 v3 |
| Processor socket | LGA 2011-v3 |
| Processor threads | 12 |
| Product name | Intel Xeon E5-2620 v3 (15M Cache, 2.40 GHz) |
| Product Type | Processor |
| Status | Launched |
| Supported instruction sets | AVX |
| Tcase | 72.6 °C |
| Thermal monitoring technologies | Yes |
| VID voltage range | 0.65 - 1.3 V |
