| ACPI version | 5.0 |
|---|---|
| Audio chip | Realtek ALC887 |
| Audio output channels | 7.1 channels |
| BIOS memory size | 64 Mbit |
| BIOS type | UEFI AMI |
| Bundled software | Norton Internet Security (OEM version) cFosSpeed |
| Clear CMOS jumper | Yes |
| Compatible processor series | Intel® Celeron®, Intel® Pentium® |
| Component for | PC |
| CPU fan connector | Yes |
| Depth | 193 mm |
| DVI-D ports quantity | 1 |
| ECC | Yes |
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN | Yes |
| Front panel audio connector | Yes |
| Graphics adapter family | Intel |
| HDMI version | 1.4 |
| Maximum resolution | 4096 x 2160 pixels |
| Memory channels | Dual-channel |
| Memory slots type | DIMM |
| Microphone in | Yes |
| Motherboard chipset | Intel® B150 |
| Motherboard form factor | Micro ATX |
| Non-ECC | Yes |
| Number of memory slots | 4 |
| Number of SATA connectors | 6 |
| On-board graphics adapter | No |
| PC Health Monitoring | CPU,FAN,Temperature,Voltage |
| PCI Express x1 Slots | 2 |
| Power source type | ATX |
| Processor socket | LGA 1151 (Socket H4) |
| S/PDIF out connector | Yes |
| Supported memory clock speeds | 2133 MHz |
| TPM connector | Yes |
| Width | 226 mm |
| Windows operating systems supported | Yes |
