Back to the Office 209.99 GBP
209.99 GBP
10-12-2025 01:46:03
| 64-bit Support | Yes |
|---|---|
| Addressable RGB | Yes |
| AMD CrossFire Support | N/A |
| Audio | Realtek ALC1220 7.1 HD Audio |
| Audio line in ports | 1 x 3.5mm Jack |
| Audio Line Out Ports | 3 x 3.5mm Jacks |
| Bluetooth | Yes |
| Bluetooth version | 5.0 |
| Board dimensions | 170 x 170 mm |
| Chassis intrusion connector | 1 x Chassis Intrusion |
| Chipset | Intel Z390 |
| Chipset manufacturer | Intel |
| Cooling fan support | 1 x CPU Fan1 x Water Pump Fan1 x Chassis Fan |
| CPU Socket | Socket 1151 |
| Displayport connection | Yes |
| DisplayPorts | 1 x DisplayPort 1.2 |
| Drivers | Included |
| DVI connection | No |
| Firewire | No |
| Form factor | Mini-ITX Motherboard |
| Front panel connectors | 1 x Front Panel1 x Front Audio |
| HDMI connection | Yes |
| Integrated Graphics Supported | Yes |
| Integrated Sound | Realtek ALC1220 |
| Internal USB 3.0 Header | Yes |
| Length | 170 mm |
| M.2 Support | Yes |
| Maximum Installed Processors | 0 (1) |
| Maximum memory capacity | 32GB |
| Memory channel | Dual |
| Memory slot | 2 x DIMM |
| Memory type | DDR4 |
| Memory Type ECC | ECC/Non-ECC |
| Memory Type R/U | UDIMM (Unbuffered) |
| Motherboard form factor | ITX |
| Motherboard Power Connectors | 4 + 4-Pin |
| Multi GPU Support | No |
| Network Interface Type | Wired Gigabit LAN (10/100/1000) |
| Number of PCI Express Slots | 1 x PCI Express 3.0 x16 |
| On-board Audio Type | 7.1 |
| On-Board Graphics Connectors | None |
| On-board RGB Control | ASRock RGB LED |
| Power connector port | 1 x 20+4-pin ATX1 x 4+4-pin EPS |
| RAID Format | RAID 0, 1, 5, 10 |
| Raid supported | Yes |
| RGB Header Type | 3-Pin ARGB |
| RJ-45 ports | 1 x RJ-45 |
| SATA III Support | Yes |
| SATA Supported | Yes |
| Skip audio test | No |
| Software Included | UtilitiesAntiVirus Software (Trial Version)Google Chrome Browser and Toolbar |
| Storage Mode Support | AHCI Hot Plug NCQ RAID 0 RAID 1 RAID 10 RAID 5 |
| Thunderbolt | No |
| USB 3.0 Support | Yes |
| USB 3.1 Support | Yes |
| USB Connectors | 1 x USB 3.01 x USB 2.0 |
| USB Ports | 6 port(s) |
| VGA connection | No |
| Water Cooled | No |
| WiFi Speed | 1733 Mbps |
| Wireless LAN | Yes |
| Wireless Network | Yes |
