| Bus Type | QPI |
|---|---|
| Cabling technology | 10/100/1000Base-T(X) |
| Chassis type | Rack (2U) |
| Compatible operating systems | Microsoft Windows Server Red Hat Enterprise Linux SUSE Linux Enterprise Server VMware vSphere |
| Depth | 800 mm |
| ECC supported by processor | Yes |
| Embedded options available | Yes |
| Energy Star certified | Yes |
| Enhanced intel speedstep technology | Yes |
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN | Yes |
| Execute disable bit | Yes |
| Graphics adapter | G200eR2 |
| Graphics adapter family | Matrox |
| Height | 87 mm |
| Hot-Plug support | Yes |
| Hot-swap | Yes |
| Idle states | Yes |
| Intel 64 | Yes |
| Intel Demand Based Switching | Yes |
| Intel enhanced halt state | Yes |
| Intel flex memory access | No |
| Intel trusted execution technology | Yes |
| Intel TSX-NI | Yes |
| Internal memory | 16 GB |
| Internal memory type | DDR4-SDRAM |
| Maximum internal memory | 1536 GB |
| Maximum number of PCI Express lanes | 40 |
| Maximum storage capacity | 147.6 TB |
| Memory channels supported by processor | Quad |
| Memory clock speeds supported by processor | 1600,1866,2133 MHz |
| Memory slots | 24 |
| Number of processors installed | 1 |
| On-board graphics adapter | Yes |
| Operating altitude | 0 - 3050 m |
| Operating system installed | No |
| Optical drive type | No |
| PCI Express slots version | 3.0 |
| Power supply | 550 W |
| Processor ARK ID | 92986 |
| Processor boost frequency | 3 GHz |
| Processor cache | 20 MB |
| Processor cache type | Smart Cache |
| Processor code | SR2R6 |
| Processor codename | Broadwell |
| Processor cores | 8 |
| Processor family | Intel® Xeon® E5 v4 |
| Processor frequency | 2.1 GHz |
| Processor lithography | 14 nm |
| Processor model | E5-2620V4 |
| Processor operating modes | 64-bit |
| Processor package size | 52.5 x 51 mm |
| Processor series | Intel Xeon E5-2600 v4 |
| Processor socket | LGA 2011-v3 |
| Rack mounting | Yes |
| Rack rails | Yes |
| RAID support | Yes |
| Redundant fans support | Yes |
| Stepping | R0 |
| Supported storage drive interfaces | SAS,Serial ATA |
| Tcase | 74 °C |
| Thermal monitoring technologies | Yes |
| Weight | 19 kg |
| Width | 446 mm |
