| AC input frequency | 50 - 60 Hz |
|---|---|
| AC input voltage | 90-240 V |
| Bays | 16 Bay |
| Cables included | AC, SAS |
| Chassis type | Rack (3U) |
| Colour | Black |
| Cooling | Fan |
| Depth | 528.3 mm |
| Device class | Large Enterprise Business |
| Dimensions | 442.4 x 130 x 528.3 (WxHxD mm) |
| DOM Module | No |
| Drive Form Factor Support | 16 x 2.5"/3.5" |
| Drive Interface Support | 16 x SAS 3 (12Gbps) / SATA 3 (6Gbps) |
| External Connectivity | 3 x 12G Mini SAS Connector 1 x COM Port (Reserved) 3 x Mini SAS 1 x SDB |
| Height | 130 mm |
| Host ports | 4 |
| Installed storage drive type | No |
| Internal Flash Memory | No |
| LAN Type | N/A |
| LED indicators | Fan fail, HDD, LAN, Status, System |
| Maximum power consumption | 204.4 W |
| Maximum storage capacity | 128 TB |
| Maximum supported storage capacity | 1275068416 MB |
| Noise level | 36.7 dB |
| Number of power supply units | 1 |
| Operating relative humidity | 5 - 95 % |
| Operating temperature | 0 - 40 °C |
| Power supply unit PSU capacity | 650 W |
| PSU Type | Redundant/Hot Swap |
| RAID levels | 0, 1, 5, 6 |
| Redundant power supply RPS support | Yes |
| Serial interface type | SATA |
| Storage drive interface | Serial ATA II, Serial ATA III |
| Storage drive size | 3.5" |
| Storage drives installed | No |
| Supported storage drive interfaces | SAS,Serial ATA,Serial ATA II,Serial ATA III |
| Supported storage drive types | HDD,SSD |
| USB connectivity | No |
| Weight | 18.14 kg |
| Width | 442.4 mm |
