| 80 PLUS certification | 80 PLUS Bronze |
|---|---|
| AC input frequency | 50/60 Hz |
| AC input voltage | 100 - 240 V |
| Bearing technology | Sleeve |
| Cabling Type | Non-Modular |
| Certification | cTUVus, TUV, CB, CCC, BSMI, CE, FCC |
| Colour | Black |
| Combined power (+12V) | 540 W |
| Combined power (+3.3V) | 100 W |
| Combined power (+5Vsb) | 12.5 W |
| Combined power (-12V) | 3.6 W |
| Cooling type | Active |
| Fan location | Top |
| Input current | 10 A |
| Max output current (+12V) | 45 A |
| Max output current (+3.3V) | 15 A |
| Max output current (+5Vsb) | 2.5 A |
| Max output current (-12V) | 0.3 A |
| Mean time between failures | 100000 h |
| Motherboard power cable length | 55 cm |
| Motherboard power connector | 20+4 pin ATX |
| Number of fans | 1 fan(s) |
| Number of sata power connectors | 6 |
| On/off switch | Yes |
| Operating temperature | 0 - 50 °C |
| PCI Express power connectors (6+2 pin) | 2 |
| Peripheral (Molex) power connectors (4-pin) | 3 |
| Power protection features | Over current, Over power, Over voltage, Short circuit |
| Power supply unit (PSU) form factor | ATX |
| Purpose | PC |
| Sustainability certificates | CE, ENERGY STAR, REACH, RoHS, WEEE |
