Shuttle SZ170R8V2 Barebone System with Intel Z170 Chipset and LGA 1151 Socket

A compact black barebone powered by Intel Z170, LGA1151 for Skylake i3/i5/i7 CPUs, four DDR4 slots up to 64 GB, a 500W internal PSU, dual‑channel memory, 4×SATA RAID (0/1/5/10/JBOD), HDMI and two DisplayPorts, active cooling.

Brand: SHUTTLE
Model: SZ170R8V2
MPN: SZ170R8V2
Sponsored  This site contains affiliate links for which we may receive compensation. More information
AC input frequency 50 - 60 Hz
AC input voltage 100 - 240 V
Audio output channels 7.1 channels
Audio system HDA
BIOS memory size 32 Mbit
BIOS type EFI AMI
Built-in processor No
Cable lock slot Yes
Cable lock slot type Kensington
Certification FCC, CE, BSMI, C-Tick, RoHS, ErP
Compatible processor series Intel® Celeron® G, Intel Pentium G
Cooling type Active
Depth 332 mm
Display included No
DisplayPorts quantity 2
Drivers included Yes
Energy Star certified Yes
Ethernet LAN Yes
Graphics adapter family Intel
HDMI ports quantity 1
Height 198 mm
Keyboard included No
LED indicators HDD,Power
Linux operating systems supported Yes
Maximum internal memory 64 GB
Memory channels Dual-channel
Memory slots type DIMM
Memory voltage 1.2 V
Microphone in Yes
Motherboard chipset Intel® Z170
Mouse included No
Number of memory slots 4
On-board graphics adapter No
Operating system installed No
Power cord included Yes
Power supply 500 W
Power supply type Internal power supply unit
Processor socket LGA 1151 (Socket H4)
Product Type PC barebone
Quick start guide Yes
RAID levels 0,1,5,10,JBOD
Safety ETL, CB, BSMI
Storage drive interface Serial ATA III
Storage drive sizes supported 3.5"
Supported memory clock speeds 2133 MHz
Supported storage drive types HDD,SSD
Wi-Fi No
Width 216 mm
