| ACPI version | 5.0 |
|---|---|
| Audio chip | Realtek ALC1150 |
| Audio output channels | 7.1 channels |
| BIOS memory size | 128 Mbit |
| BIOS type | UEFI AMI |
| Clear CMOS jumper | Yes |
| Compatible processor series | Intel Core i7 |
| Component for | PC |
| CPU fan connector | Yes |
| Depth | 305 mm |
| ECC | No |
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN | Yes |
| Front panel audio connector | Yes |
| Maximum number of SMP processors | 1 |
| Memory channels | Quad-channel |
| Memory slots type | DIMM |
| Microphone in | Yes |
| Motherboard chipset | Intel® X99 |
| Motherboard chipset family | Intel |
| Motherboard form factor | ATX |
| Non-ECC | Yes |
| Number of memory slots | 8 |
| Number of SATA III connectors | 10 |
| Parallel processing technology support | 2-Way CrossFireX,3-Way CrossFireX,3-Way SLI,4-Way CrossFireX |
| PCI Express x1 Slots | 3 |
| PCI Express x16 slots | 4 |
| Processor socket | LGA 2011-v3 |
| RAID levels | 0,1,5,10 |
| S/PDIF out port | Yes |
| Supported memory clock speeds | 2133,2400,2666,2800,3000,3200 MHz |
| Supported storage drive interfaces | M.2,Serial ATA,Serial ATA III |
| TPM connector | Yes |
| Width | 244 mm |
| Windows operating systems supported | Yes |
