| ACPI version | 5.0 |
|---|---|
| ATX Power connector 24-pin | Yes |
| Audio output channels | 7.1 channels |
| BIOS memory size | 16 Mbit |
| BIOS type | UEFI |
| Cables included | SATA |
| Chassis intrusion connector | Yes |
| Clear CMOS button | Yes |
| Component for | Workstation |
| CPU fan connector | Yes |
| Depth | 267 mm |
| Discrete graphics support | Yes |
| ECC | Yes |
| eSATA ports quantity | 2 |
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN | Yes |
| HDD interface | Serial ATA |
| Headphone outputs | 1 |
| Intel Xeon series | E5-1600,E5-2600 |
| LAN controller | Intel I210AT |
| Lithography | 22 nm |
| Maximum internal memory | 131072 MB |
| Memory channels | Quad |
| Microphone in | Yes |
| Motherboard chipset | Intel® X99 |
| Motherboard form factor | SSI CEB |
| Non-ECC | Yes |
| Number of chassis fan connectors | 4 |
| Number of DIMM slots | 8 |
| Parallel processing technology support | 4-Way CrossFireX,4-Way SLI |
| PCI Express x16 Gen 3.x slots | 7 |
| Processor manufacturer | Intel |
| Processor socket | LGA 2011-v3 |
| RAID levels | 0, 1, 5, 10 |
| Supported memory clock speeds | 2133,2400,2666,2800,3000,3200 MHz |
| TPM connector | Yes |
| Width | 305 mm |
