| 12v power connector | Yes |
|---|---|
| ACPI version | 6.1 |
| AMD CrossFire Support | 2-Way CrossFire |
| ATX Power connector 24-pin | Yes |
| Audio | Realtek ALC887-VD2 8-Channel HD Audio |
| Audio chip | Realtek ALC887-VD2 |
| Audio output channels | 7.1 channels |
| Back Audio Jacks | 3 |
| Back DVI-D Ports | 1 |
| BIOS memory size | 128 Mbit |
| BIOS type | UEFI AMI |
| Board dimensions | 305 x 234 mm |
| Cables included | SATA |
| Chipset | AMD B450 |
| Clear CMOS jumper | Yes |
| Compatible processor series | AMD Ryzen |
| Component for | PC |
| Cooling fan support | 1 x CPU / 3 x Chassis |
| CPU fan connector | Yes |
| CPU Interface | Socket AM4 |
| Depth | 234 mm |
| Dimensions | 23 x 39 x 40cm (W x H x D) |
| Drivers included | Yes |
| ECC | Yes |
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN | Yes |
| Form factor | ATX |
| Front panel audio connector | Yes |
| Front panel connector | Yes |
| Gross weight | 1.08Kg |
| HDMI version | 2.0b |
| LAN controller | Realtek RTL8111H |
| LAN Speed | 10/100/1000 |
| Manual | Yes |
| Maximum internal memory | 65536 MB |
| Maximum memory capacity | 64GB (4x16GB) |
| Maximum resolution | 4096 x 2160 pixels |
| Memory channels | Dual |
| Memory slots type | DIMM |
| Memory speed | DDR4 - 2133 DDR4 - 2400 DDR4 - 2666 DDR4 - 2800(OC) DDR4 - 3000(OC) DDR4 - 3200(OC) |
| Memory Type ECC | ECC/Non-ECC |
| Memory Type R/U | UDIMM (Unbuffered) |
| Motherboard chipset family | AMD |
| Network Chip | 1 x Realtek RTL8111H (Gigabit LAN) |
| Number of SATA III connectors | 6 |
| NVIDIA SLI Support | Not Supported |
| Parallel processing technology support | CrossFireX |
| Primary GPU Interface | PCIe 3.0 (x16) |
| QPI Speed | N/A |
| RAID | Raid 0/1/10 |
| RAM Slots | 4 x 288-pin |
| Refresh rate | 60Hz 2Ms Response Time |
| SATA Support | SATA3 / M.2 |
| Storage Mode Support | NVMe Boot (via M.2 PCIe Slot) NVMe Boot (via PCIe 3.0 Slot) RAID 0 RAID 1 RAID 10 |
| Supported memory clock speeds | 2133,2400,2666,2800,3000,3200 MHz |
| System management BIOS SMBIOS version | 3.1 |
| Unbuffered memory | Yes |
| Wake-on-LAN ready | Yes |
| Water Cooled | No |
| Width | 305 mm |
| Windows operating systems supported | Windows 10 Education x64,Windows 10 Enterprise x64,Windows 10 Home x64,Windows 10 Pro x64 |
