| ACPI version | 6.0 |
|---|---|
| Addressable RGB | No |
| Audio codec | Realtek® ALC S1220A 8-Channel High Definition Audio CODEC featuring Crystal Sound 3 |
| Audio line in ports | 5 x Audio I/O |
| Audio output channels | 7.1 channels |
| BIOS memory size | 128 Mbit |
| BIOS type | UEFI AMI |
| Bluetooth | No |
| Chassis intrusion connector | Yes |
| Chipset | Intel Z270 |
| Chipset manufacturer | Intel |
| Colours | Black |
| Compatible processor series | Intel® Celeron®, Intel® Pentium® |
| Component for | PC |
| CPU | Intel Socket 1151 for 7th/6th Generation Core i7/i5/i3/Pentium/Celeron Processors |
| CPU fan connector | Yes |
| CPU Socket | Socket 1151 |
| Depth | 244 mm |
| Displayport connection | Yes |
| DisplayPorts | 1 x DisplayPort |
| DVI connection | Yes |
| Ethernet LAN | Yes |
| Firewire | No |
| Form factor | ATX, 305 x 244 mm |
| Front panel connector | Yes |
| Graphics | Intel HD Graphics support |
| Graphics chipset | None |
| Graphics memory | 1024 MB |
| HDMI connection | Yes |
| Integrated Graphics Supported | Yes |
| Integrated Network | Intel I219-V Gigabit LAN Controller |
| Internal USB 3.0 Header | Yes |
| Keyboard/mouse combo port | 1 x PS/2 |
| LAN | Intel I219V, 1 x Gigabit LAN Controller with ASUS LAN Guard |
| M.2 Support | Yes |
| Maximum Installed Processors | 0 (1) |
| Maximum internal memory | 64 GB |
| Memory | 4 x DIMM, Max. 64GB, DDR4, 2133 to 3866 (OC) MHz Non-ECC, Un-buffered Memory |
| Memory channel | Dual |
| Memory channels | Dual-channel |
| Memory slot | 4 x DIMM Slots |
| Memory slots type | DIMM |
| Memory speed | 3866 MHz |
| Microphone in | Yes |
| Motherboard form factor | ATX |
| Motherboard Power Connectors | 4 + 4-Pin |
| Multi GPU Support | Both |
| Multi-GPU Support | Supports NVIDIA 2-Way SLI and AMD 3-way CrossFireX Technology |
| Non-ECC | Yes |
| Number of chassis fan connectors | 2 |
| Number of PCI Express Slots | 6 slot(s) |
| On-board RGB Control | ASUS Aura Sync |
| Processor socket | LGA 1151 (Socket H4) |
| RAID | Support Raid 0, 1, 5, 10 |
| Raid supported | Yes |
| RJ-45 ports | 1 x RJ-45 |
| S/PDIF out port | Yes |
| SATA Connectors | 6 x SATA 6Gb/s |
| SATA III Support | Yes |
| SATA Supported | Yes |
| Skip audio test | No |
| Supported memory clock speeds | 2133,2400,2666,2800,3000,3200,3300,3333,3400,3466,3600,3733,3866 MHz |
| Thunderbolt | Yes |
| TPM connector | Yes |
| Unbuffered memory | Yes |
| USB 2.0 connectors | 3 |
| USB 3.0 Support | Yes |
| USB 3.1 Support | Yes |
| VGA connection | No |
| Wake-on-LAN ready | Yes |
| Width | 305 mm |
| Wireless Network | No |
