| ACPI version | 5.0 |
|---|---|
| Audio codec | Realtek ALC1220 codec |
| Audio output channels | 7.1 channels |
| BIOS memory size | 16 Mbit |
| BIOS type | UEFI AMI |
| Bluetooth | Yes |
| Bluetooth version | 4.2 |
| Chassis intrusion connector | Yes |
| Chipset | Intel Z270 |
| Clear CMOS jumper | Yes |
| Compatible processor series | Intel® Celeron®, Intel® Pentium® |
| Component for | PC |
| CPU | Intel Socket 1151 for 7th/6th Generation Core i7/i5/i3/Pentium/Celeron Processors |
| CPU fan connector | Yes |
| DVI-D ports quantity | 1 |
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN | Yes |
| Form factor | Mini-ITX, 170 x 170 mm |
| Front panel audio connector | Yes |
| Front panel connector | Yes |
| Graphics | Intel HD Graphics support |
| HDMI ports quantity | 2 |
| LAN | 2x Intel Gigabit LAN ports (10/100/1000 Mbit) |
| Linux operating systems supported | Yes |
| Maximum internal memory | 32 GB |
| Memory | 2x DIMM, Max. 32GB, DDR4, 2133 to 4000(OC) MHz Non-ECC, Un-buffered Memory |
| Memory slots type | DIMM |
| Microphone in | Yes |
| Motherboard chipset family | Intel |
| Motherboard form factor | Mini ITX |
| Non-ECC | Yes |
| Number of SATA III connectors | 6 |
| Power source type | ATX |
| Processor socket | LGA 1151 (Socket H4) |
| RAID | Support for RAID 0, RAID 1, RAID 5, and RAID 10 |
| S/PDIF out connector | Yes |
| S/PDIF out port | Yes |
| Supported memory clock speeds | 2133,2400,2666,2800,3000,3200,3300,3333,3400,3466,3600,3666,3733,3800,3866,4000 MHz |
| Supported memory types | DDR4-SDRAM |
| Supported storage drive types | HDD,SSD |
| Unbuffered memory | Yes |
| Warranty | 24 months |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11a,Wi-Fi 5 (802.11ac),802.11b,802.11g,Wi-Fi 4 (802.11n) |
