632.86 USD
632.86 GBP
10-03-2026 10:42:57
| ACPI version | 5.0 |
|---|---|
| Audio chip | Realtek ALC888S |
| BIOS type | UEFI AMI |
| Bundled software | IPMI2.0, SPM, SuperDoctor 5 |
| Chassis intrusion connector | Yes |
| Compatible processor series | Intel® Core™ i3, Intel Core i5, Intel Core i7 |
| Component for | Workstation |
| Depth | 243.8 mm |
| DisplayPorts quantity | 1 |
| DVI port | Yes |
| ECC | Yes |
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN | Yes |
| HDD interface | Serial ATA III |
| Intel Xeon series | E3-1200 |
| LAN controller | Intel® I210-AT, Intel I219LM |
| Maximum internal memory | 64 GB |
| Memory voltage | 1.2 V |
| Motherboard chipset | Intel® C236 |
| Motherboard form factor | ATX |
| Non-ECC | Yes |
| Number of chassis fan connectors | 4 |
| Number of COM connectors | 2 |
| Number of SATA III connectors | 8 |
| On-board graphics adapter model | Aspeed AST2400 |
| PC Health Monitoring | FAN,LED,Power supply,Temperature,Voltage |
| Plug and play | Yes |
| Processor manufacturer | Intel |
| Processor socket | LGA 1151 (Socket H4) |
| RAID levels | 0,1,5,10 |
| RAID support | Yes |
| RoHS compliance | Yes |
| Supported memory clock speeds | 1600,1866,2133,2400 MHz |
| Thermal power | 80 W |
| TPM connector | Yes |
| Unbuffered memory | Yes |
| Wi-Fi | No |
| Width | 304.8 mm |
